AWG to Metric
American Wire Gauge Conversion Table
The table below can be used to convert American Wire Gauge (AWG) to square mm cross sectional area:
|
American Wire Gauge |
Diameter | Diameter | Cross Sectional Area |
| AWG | inches | mm | mm² |
| 0 | 0.46 | 11.68 | 107.16 |
| 0 | 0.41 | 10.4 | 84.97 |
| 0 | 0.36 | 9.27 | 67.40 |
| 0 | 0.32 | 8.25 | 53.46 |
| 1 | 0.29 | 7.35 | 42.39 |
| 2 | 0.26 | 6.54 | 33.61 |
| 3 | 0.23 | 5.83 | 26.65 |
| 4 | 0.20 | 5.19 | 21.14 |
| 5 | 0.18 | 4.62 | 16.76 |
| 6 | 0.16 | 4.11 | 13.29 |
| 7 | 0.14 | 3.67 | 10.55 |
| 8 | 0.13 | 3.26 | 8.36 |
| 9 | 0.11 | 2.91 | 6.63 |
| 10 | 0.10 | 2.59 | 5.26 |
| 11 | 0.09 | 2.30 | 4.17 |
| 12 | 0.08 | 2.05 | 3.31 |
| 13 | 0.07 | 1.83 | 2.63 |
| 14 | 0.06 | 1.63 | 2.08 |
| 15 | 0.06 | 1.45 | 1.65 |
| 16 | 0.05 | 1.29 | 1.31 |
| 17 | 0.05 | 1.15 | 1.04 |
| 18 | 0.04 | 1.02 | 0.82 |
| 19 | 0.04 | 0.91 | 0.65 |
| 20 | 0.03 | 0.81 | 0.52 |
| 21 | 0.03 | 0.72 | 0.41 |
| 22 | 0.03 | 0.65 | 0.33 |
| 23 | 0.02 | 0.57 | 0.26 |
| 24 | 0.02 | 0.51 | 0.20 |
| 25 | 0.02 | 0.45 | 0.16 |
| 26 | 0.02 | 0.40 | 0.13 |
