- Sku: 3070500
Croytape Adhesive Kapton® Tape
This is a cut-to-order product, ALL SIZES ARE AVAILABLE
Order as Backorder, fulfilled within 1 working day
Order by 2pm for next day UK delivery*
Size out of stock? Contact us
International orders: shipping calculated after checkout
DESCRIPTION
This tape, made from polyimide film, is an electrical insulation material that is well-known for its outstanding electrical, mechanical, thermal and chemical properties. Recommended for a variety of high temperature protection and insulation applications (180 °C Thermal Class H).
Please note: Kapton® is a DuPont registered trademark.
APPLICATIONS
- Electrical insulation
- High temperature masking
- Protection of PCB gold fingers, plug-in connectors and switches during wave soldering
- Electrical insulation of coils, transformers, wires and cables for Class H (180°C) applications
TECHNICAL INFO
| Unit | Nominal Value | Test Method | |
| Total Thickness | Mm | 0.067 | TM02 |
| Adhesive Thickness | g/m2 | 0.045 | TM21 |
| Carrier Thickness | Mm | 0.025 | TM02 |
| Peel Adhesion | N/25mm | 7.0 | TM31 |
| Tensile Strength | N/25mm | 110 | TM36 |
| Elongation at Break | % | 35 | TM36 |
| Breakdown Voltage | kV | 6.35 | AFERA 4011 |
FEATURES AND BENEFITS
- High temperature resistance – removes cleanly and in one piece after being exposed to high temperatures
- Length: 33M
- High mechanical resistance – high strength backing provides superior puncture, tear and abrasion resistance
- Resistance to chemical attack
- Excellent thin electrical insulation
- Highly conformable
- Good resistance to most alcohols, esters, ketones and oils
MATERIAL DATA
| Product Code | 307 |
| Material | Polyimide film single coated with cured silicone adhesive |
| Standard Colour | Amber |
| Total Thickness – mm | 0.067 |
| Operating Temperature – °C | 180 continuous (short term 400°C) |
| Elongation at Break – % | 35 |
| Dielectric Strength – kV | 6.35 |
| Tensile Strength – N/25mm | 110 |
| Adhesive Thickness – mm | 0.025 |
| Relevant Specifications | UL510 |
PRICE MATRIX
|
Size |
1-23 Rolls |
24-47 Rolls |
48+ Rolls |
|
5 mm |
£5.45 |
£5.09 |
£4.72 |
|
6 mm |
£6.56 |
£6.13 |
£5.69 |
|
7 mm |
£7.66 |
£7.15 |
£6.64 |
|
8 mm |
£8.75 |
£8.17 |
£7.58 |
|
10 mm |
£10.90 |
£10.18 |
£9.45 |
|
12 mm |
£12.12 |
£11.31 |
£10.50 |
|
19 mm |
£19.15 |
£17.88 |
£16.60 |
|
25 mm |
£25.27 |
£23.58 |
£21.90 |
|
38 mm |
£38.31 |
£35.75 |
£33.20 |
|
40 mm |
£40.95 |
£38.22 |
£35.49 |
|
50 mm |
£51.63 |
£48.19 |
£44.74 |
