- Sku: 3000304
CroyTape Adhesive Yellow Polyester Tape
This is a cut-to-order product, ALL SIZES ARE AVAILABLE
Order as Backorder, fulfilled within 1 working day
Order by 2pm for next day UK delivery*
Size out of stock? Contact us
International orders: shipping calculated after checkout
DESCRIPTION
Consisting of a transparent polyester film coated with yellow rubber based pressure sensitive adhesive system, this tape is designed for use for high temperature insulation transformer coil finishing and applications where heat resistance, conformability and chemical resistance are required.
Conditions: Store in a cool dry place away from sunlight and direct heat sources. As far as the storage conditions are respected, the product is guaranteed for 24 months.
APPLICATIONS
- Electrical insulation
- Mould taping
- Coil Winding
- Splicing
- Fixiing
TECHNICAL INFO
|
Tensile strength (N/25mm) |
110 |
|
Elongation (%) |
90 |
|
Temperature Resistance (°C) |
UL B / 130 |
|
Dielectric Strength (Kv) |
4 |
FEATURES AND BENEFITS
- Good dielectric strength
- Length: 66M
- Good temperature resistance
- Good chemical resistance
- Will not break or tear during application or removal
- Protects against abrasion from rough surfaces, fumes and chemicals
- Flexible backing conforms readily to irregular surfaces
- High performance adhesive resists degradation from chemicals and fumes
MATERIAL DATA
| Product Code | 300 |
| Material | Polyester with yellow thermosetting adhesive |
| Carrier Thickness | 0.023 |
| Total Thickness | 0.053 |
| Adhesive | Yellow thermosetting rubber |
| Adhesion to Steel (N/25mm) | 14 |
| Adhesion to Backing (N/25mm) | 4.5 |
| UL Approval | E178430 |
PRICE MATRIX
|
Size |
1-20 Rolls |
21-49 Rolls |
50 Rolls + |
|
3 mm |
£0.5130 |
£0.4590 |
£0.4050 |
|
4 mm |
£0.6840 |
£0.6120 |
£0.5400 |
|
5 mm |
£0.8550 |
£0.7650 |
£0.6750 |
|
6 mm |
£1.0450 |
£0.9350 |
£0.8250 |
|
7 mm |
£1.2160 |
£1.0880 |
£0.9600 |
|
8 mm |
£1.3870 |
£1.2410 |
£1.0950 |
|
9 mm |
£1.5580 |
£1.3940 |
£1.2300 |
|
10 mm |
£1.7290 |
£1.5470 |
£1.3650 |
|
11 mm |
£1.9000 |
£1.7000 |
£1.5000 |
|
12 mm |
£2.0710 |
£1.8530 |
£1.6350 |
|
13 mm |
£2.2420 |
£2.0060 |
£1.7700 |
|
14 mm |
£2.4130 |
£2.1590 |
£1.9050 |
|
15 mm |
£2.5840 |
£2.3120 |
£2.0400 |
|
16 mm |
£2.7740 |
£2.4820 |
£2.1900 |
|
17 mm |
£2.9450 |
£2.630 |
£2.3250 |
|
18 mm |
£3.1160 |
£2.7880 |
£2.4600 |
|
19mm |
£3.2870 |
£2.9410 |
£2.5950 |
|
20 mm |
£3.4580 |
£3.0940 |
£2.7300 |
|
21 mm |
£3.6290 |
£3.2470 |
£2.8650 |
|
22 mm |
£3.8000 |
£3.4000 |
£3.0000 |
|
23 mm |
£3.9710 |
£3.5530 |
£3.1350 |
|
24 mm |
£4.1420 |
£3.7060 |
£3.2700 |
|
25 mm |
£4.3130 |
£3.8590 |
£3.4050 |
|
26 mm |
£4.4840 |
£4.0120 |
£3.5400 |
|
27 mm |
£4.6740 |
£4.1820 |
£3.6900 |
|
28 mm |
£4.8450 |
£4.3350 |
£3.8250 |
|
30 mm |
£5.1870 |
£4.6410 |
£4.0950 |
|
32 mm |
£5.5290 |
£4.9470 |
£4.3650 |
|
33 mm |
£5.7000 |
£5.1000 |
£4.5000 |
|
34 mm |
£5.8710 |
£5.2530 |
£4.6350 |
|
35 mm |
£6.0420 |
£5.4060 |
£4.7700 |
|
37 mm |
£6.3840 |
£5.7120 |
£4.7040 |
|
38 mm |
£6.5740 |
£5.8820 |
£5.1900 |
|
40 mm |
£6.9160 |
£6.1880 |
£5.4600 |
|
41 mm |
£7.0870 |
£6.3410 |
£5.5950 |
|
42 mm |
£7.2580 |
£6.4940 |
£5.7300 |
|
44 mm |
£7.6000 |
£6.8000 |
£6.0000 |
|
45 mm |
£7.7710 |
£6.9530 |
£6.1350 |
|
50 mm |
£8.6450 |
£7.7350 |
£6.8250 |
|
52 mm |
£8.9870 |
£8.0410 |
£7.0950 |
|
53 mm |
£9.1580 |
£8.1940 |
£7.2300 |
|
55 mm |
£9.4886 |
£8.4898 |
£7.4910 |
|
75 mm |
£12.9580 |
£11.5940 |
£10.2300 |
